Slitting and Rewinding Machine for Surface Rolling

Slitting and Rewinding Machine For Surface Rolling







This machine adopts center- rewinding and surface contract rewinding method.Having light electric automatic corrective adjustment device, constant magnet powder brake and clutch device.With automatic counting and stopping device. Adopted frequency conversion to control speed.









Model	HYFQ-D1150	HYFQ-D1350	HYFQ-D1650
Max width of raw material	1120mm	1320mm	1620mm
Max.Parent web diameter	Φ1500mm	Φ1500mm	Φ1500mm
Max.Rewinding diameter	Φ680mm	Φ680mm	Φ680mm
Min width of slitting	3mm	3mm	3mm
Speed	10-400m/min	10-400m/min	10-400m/min
Thinkness of raw material	0.008-0.5mm	0.008-0.5mm	0.008-0.5mm
Total power	14kw	16kw	19kw
Machine dimensions	3500×2500×1450mm	3500×2700×1450mm	3500×2900×1450mm
Machine weight	3800kg	4300kg	4800kg









1. What is the role of the round knife?

Rotary shearing knives, including slitting blade, rotary shear & blade foundation.

Aligned rotation, improved slitting edge..



2. What is the machine core Components?

PLC, Motor



3. Is the body stable and corrosion resistant?

Simple design with good practice welding and easy for maintenance.Stable frame for the efficiency throughout



4. Is the machine easy to use?

Simplified logic control.Easy to operate.Complete functions, stepless speed regulation.



5. What is the function of the meter counter?

Set the required slitting length and stop automatically

Precision slitting



6. What is the membrane heating function?

The film is heated, and the heating function is turned on as needed.

Softening of the film for easy slitting



7. What is the function of mechanical transmission?

Adopt belt drive to ensure the same speed of upper and lower reels



8. What is the rewind reset function?

Jog the reset button, the reel is reset, it is convenient to install and remove the reel, load and unload materials
