T-Shirt Bag Making Machine

HOWIE T-Shirt Bag Making Machine is engineered for plastic packaging plants producing T-shirt bags, vest bags, grocery bags, and shopping bags from HDPE and LDPE films.

Feature

HOWIE T-Shirt Bag Making Machine

High-Speed Automatic T-Shirt Bag Production Line
Stable Production | Precise Sealing | Low Maintenance | Custom Configuration

HOWIE T-Shirt Bag Making Machine is engineered for plastic packaging plants producing T-shirt bags, vest bags, grocery bags, and shopping bags from HDPE and LDPE films. Backed by 15+ years of manufacturing experience, this system delivers reliable output, consistent bag quality, and reduced operating costs.

Product Overview

The machine integrates film feeding, heat sealing, cutting, counting, and collection into a continuous automated workflow. It serves plastic packaging manufacturers, supermarket suppliers, and industrial converters for:

T-Shirt Shopping Bags

Retail checkout and promotional bags.

Vest Bags

Everyday carry bags for grocery and convenience stores.

Grocery & Retail Packaging

Durable designs for high daily turnover.

Garbage Bags

Household and commercial waste bags.

Custom PE Bags

Flexible production tailored to specific client dimensions.

Key Advantages

High-Speed Stable Operation
Maintains a stable running speed of 120–250 cuts/min depending on bag size and thickness. The optimized transmission design minimizes production bottlenecks during heavy-duty shifts.

Precise Bag Length Control
Powered by a high-performance servo motor and PLC control system. It ensures uniform dimensions across batches and significantly reduces raw material waste.

Strong Heat Sealing
The thermal heating and pressure-balancing structure secure strong, reliable bottom seals. This prevents bottom leakage under heavy loads and keeps defect rates consistently low.

Efficient Control & Maintenance
An intuitive touch-screen HMI allows fast parameter adjustment and real-time monitoring. This simplifies the operator workflow and reduces routine maintenance downtime.

Technical Specifications

Item	Specification Details
Machine Type	High-Speed Automatic T-Shirt Bag Making Machine
Compatible Materials	HDPE, LDPE, Recycled PE Blends
Production Speed	120 – 250 pcs/min
Max. Bag Width	Customizable (Standard: 200 mm – 700 mm)
Max. Bag Length	Customizable (Standard: 300 mm – 1000 mm)
Film Thickness	0.01 mm – 0.10 mm
Control System	PLC Touch Screen with Servo Motor Drive
Power Supply	Customized to Country Standard (3-Phase, 220V/380V/415V, etc.)

Machine Working Process

01/

Film Feeding
Raw film feeds smoothly into the tension-controlled unit.

02/

Length Setting
Servo system measures exact film lengths per cycle.

03/

Heat Sealing
Thermal sealing bar creates a uniform bottom seal.

04/

Cutting
Automatic mechanical knife cleanly separates finished bags.

05/

Counting & Collection
Bags are automatically batched and stacked.

Quality Control

Component Inspection

Raw electrical and mechanical parts undergo strict testing.

Precision Assembly

Assembled by senior technicians to ensure tight tolerances.

Running Test

Full-capacity operational trial run conducted in-house.

Final Inspection

Comprehensive check covering safety, cutting accuracy, and stability.

Commercial Terms & Support

Warranty

12 months on core mechanical and electrical components.

Lead Time

30–45 business days for standard models.

Technical Support

Remote troubleshooting, manuals, video guides, and optional on-site engineer dispatch.

FAQ

Q: What materials can this machine process?

A: It processes virgin HDPE/LDPE as well as biodegradable and recycled-content plastic films.

Q: What is the standard delivery time and warranty?

A: Standard delivery takes 30 to 45 days. We provide a 1-year warranty along with lifelong technical consultation.

Q: Do you offer on-site installation assistance?

A: Yes. We provide video guides and can send experienced engineers to your factory for overseas installation and operator training upon request.
