High Speed Servo Rotary Paper Cutting Machine
This high-speed servo rotary paper cutting machine is suitable for cutting the large coil packaging material, such as paper, paper plastic complex material and color printing complex material, etc.
High Speed Servo Rotary Paper Cutting Machine
This high-speed servo rotary paper cutting machine is suitable for cutting the large coil packaging material, such as paper, paper plastic complex material and color printing complex material, etc. This machine is widely used for application in the industries of paper processing and printing packaging.
Main Features:
1. With the development and competition of the paper products process industry and the printing industry, the rolling paper cutting machine has become one of the dispensable equipment in the paper products process industry and printing industry.
2. Some spare parts like electricity are made in Europe, America, and Japan, etc.
Making such a machine become a much simple operation, convenient repair with the technique of both computer well controlling and machine be combined, even more, it ensures the keeping of precision and steady of the machine when running with high speed.
3. It is widely adopted in the paper products process industry and printing industry by users.
Technical Parameter:
|
Model |
CHM-1400 |
CHM-1700 |
CHM-1900 |
|
Max width of material |
1400mm |
1700mm |
1900mm |
|
Max diameter of material |
φ1600mm |
φ1600mm |
φ1600mm |
|
Max width of cutting |
1400mm |
1700mm |
1900mm |
|
Length of cutting |
450-1450mm |
450-1450mm |
450-1450mm |
|
Max thickness of cutting |
500g/㎡ |
500g/㎡ |
500g/㎡ |
|
Height of paper pilling |
1400mm |
1400mm |
1400mm |
|
Precision |
±0.5mm |
±0.5mm |
±0.5mm |
|
Speed |
300m/min |
300m/min |
300m/min |
|
Total power |
22kw |
25kw |
28kw |
|
Machine dimensions |
11500*4000*2200mm |
11500*4300*2200mm |
11500*4500*2200mm |
|
Machine weight |
13000kg |
15000kg |
17000kg |
FAQ
1.What are your warranty and other terms?
One-year machine warranty, and whole life technical support. Spare parts are free for customers for 1 year. We can send our engineer to your factory for machine installation and operator training if you need,Customers pay for the flight tickets, meals and hotel for our engineer.Salary USD150.00 per day to our engineer.
2. What is your delivery term?
FOB, CIF, CFR usually.
3. What is your payment?
T/T.30% deposit, 70% balance before delivery.
L/C. 100% at sight.
T/T and L/C, 30% TT deposit, 70% L/C.
4. What is your delivery time?
30-60 days usually
5.Can I customize multiple rolls for unwinding?
Can customize 1 roll,2 rolls,4rolls and 6 rolls according to your requirements.
6.What is the max speed of the machine?
The max speed of the machine is 300m/min
